6.5HP GASOLINE ENGINE RECOIL START – 19mm shaft

This engine has a 19mm shaft diameter.

Whether you’re thinking industrial, agricultural or home use, this could be the engine for you.
This engine is a Jono & Johno brand, recoil start, 4 stroke, single cylinder, petrol engine with a 6.5hp capacity.
Suitable to power items such as generators, grinders, water pumps and a host of other machinery.

The engine comes with a one year parts warranty and a lifetime of after sales service.

FEATURES:

  • Air cooled, 4-stroke, OHV25 inclined single cylinder
  • 6.5hp gasoline/petrol engine
Max Power Output:  6.5hp/3600rpm
Displacement: 196cc
Bore x Stroke (mm):  68 x 54
Max Torque (n.m)/rpm] :  1.35(13.2)/2500
Ignition system: Transistor Electric / Inductive Firing
Spark Plug Type: NGK: BPR6ES Champion: RN9YC Bosch: W7DCR
Starting system: Recoil
Fuel Tank Capacity: 3.6L
Oil capacity: 0.6L
Fuel consumption: 230g/hp.h (313g/kw.h)
Air cleaner:  Semi dry, dual filter
Shaft Diameter: 19mm
Shaft Length: 58mm (61mm from seal face)
Shaft Internal Thread 5/16-24 UNF
Keyway Length: 50mm
Keyway Width: 5mm
Distance from base to centre of out put shaft: 105mm
Shaft rotation: Anti-clockwise (from output)
Weight:  16kg
SKU JPE65
Model # JPE65
Barcode # 681087038836
Brand JONO & JOHNO
Shipping Weight 17.0000kg
Shipping Width 0.050m
Shipping Height 0.050m
Shipping Length 0.050m
Shipping Cubic 0.000125000m3
Unit Of Measure ea
