SKU : JPE65
This horizontal engine has a 19mm Keyway shaft .
Whether you’re thinking industrial, agricultural or home use, this could be the engine for you.
This engine is a Jono & Johno brand, recoil start, 4 stroke, single cylinder, petrol engine with a 6.5hp capacity.
Suitable to power items such as generators, grinders, water pumps and a host of other machinery.
The engine comes with a one year parts warranty and a lifetime of after sales service.
Max Power Output: | 6.5hp/3600rpm |
Displacement: | 196cc |
Bore x Stroke (mm): | 68 x 54 |
Max Torque (n.m)/rpm] : | 1.35(13.2)/2500 |
Ignition system: | Transistor Electric / Inductive Firing |
Spark Plug Type: | NGK: BPR6ES Champion: RN9YC Bosch: W7DCR |
Starting system: | Recoil |
Fuel Tank Capacity: | 3.6L |
Oil capacity: | 0.6L |
Fuel consumption: | 230g/hp.h (313g/kw.h) |
Air cleaner: | Semi dry, dual filter |
Shaft Diameter: | 19mm |
Shaft Length: | 58mm (61mm from seal face) |
Shaft Internal Thread | 5/16-24 UNF |
Keyway Length: | 50mm |
Keyway Width: | 5mm |
Distance from base to centre of out put shaft: | 105mm |
Shaft rotation: | Anti-clockwise (from output) |
Weight: | 16kg |
Jono & Johno offers a 12-month warranty on most products.
We pride ourselves on selling good quality gear and will be fair and prompt in honouring our warranties. If you’re in trouble, we’ll help you out.
The exact warranty coverage depends on two factors:
Minor faults caused by the user
Minor faults caused by the manufacturer
Major faults caused by the manufacturer
Major faults caused by the user
If you need to return your product:
Some products are not covered by warranty, including:
If your product is out of warranty and has failed despite minimal use, contact us. We may assess it on a case-by-case basis. If a manufacturer defect is identified, we aim to be fair in resolving the issue—but this is at our discretion.
SKU | JPE65 | |
Model # | JPE65 | |
Barcode # | 681087038836 | |
Brand | JONO & JOHNO | |
Shipping Weight | 17.0000kg | |
Shipping Width | 0.250m | |
Shipping Height | 0.380m | |
Shipping Length | 0.420m | |
Shipping Cubic | 0.057268750m3 | |
Unit Of Measure | ea |
