PERLA BARB 62CC V4 CHAINSAW

Jono & Johno would like to present the 62cc Perla Barb V4 chainsaw.

This is a good solid saw which, with regular maintenance, will last a long time. This is not a throw away saw.

We stock ALL spare parts in our warehouse, so should you ever have any issues with the saw, in or out of warranty period, we’ll be able to help you out. THAT’S A GUARANTEE!

The warranty on the saw is a 12-month parts warranty. So if something goes wrong with the saw in the first 12 months of use, we can send you the parts, free of charge.

If you have any questions about our saw, don’t hesitate to give us a call or drop us an email.

PLEASE NOTE: no bar or chain included in this listing. Felling dogs and mounting bolts come in the tool kit and must be manually fitted before use.

SPECIFICATIONS:

Model: Perla Barb 62cc V4
Engine: Single cylinder, two stroke, air cooled
Displacement: 62cc
KW: 2.85
Ignition system: C. D. I.
Engine Idling speed: 3000rpm + or - 300
Max engine speed: 10000rpm
Fuel tank capacity: 550ml (19.36 fl oz)
Bar oil tank capacity: 260ml (9.15 fl oz)
Recommended bar oil: Dedicated bar oil. Do not use motor or sump oil.
Fuel: Regular unleaded petrol and 2-stroke oil (25:1)
Carburettor: Diapghram type
Spark plug: NGK = BPMR7A, Champion = RCJ6Y
Oil feeding system: Automatic pump with adjuster
Sprocket: 7 tooth 0.325
Bar Mount type: POH (Hurricane)
Maximum recommended bar size: 24"

Minimum requirements for a chainsaw box to fit this saw: 300H x 270W x 500L mm

TUNING:

Low speed setting: between 2,700 and 3,300 rpm

High speed setting: between 10,200 and 11,100 rpm

DIMENSIONS:

Gross weight (includes packaging and accessories): 6.75kgs (14.88lbs)
Net weight of saw without bar and chain: 5.7kgs (12.57lbs)
Packing size: 51x26x29cm

WARRANTY OVERVIEW

Jono & Johno offers a 12-month warranty on all products.

We pride ourselves on selling good quality kit and will be fair and prompt honouring our warranties. If you’re in trouble, we’ll help you out.

WHAT IS COVERED?

Exactly what is covered by warranty will depend on 2 things:

If the fault is due to user or manufacturer
If the fault is minor or major

Minor faults caused by user - Parts will be supplied for repair at user expense.

Minor faults caused by manufacturer - Parts will be supplied for repair, with instructions provided by us on how to carry out repair.

Major faults caused by manufacturer - Jono & Johno will facilitate a return of the product for refund or replacement at our expense. Or if you’d prefer (at our discretion and in consultation with you), we can send appropriate parts and compensate labour costs if you can carry out the repair yourself.

Major faults caused by user - Where possible parts will be supplied at user expense. Where the item cannot be repaired by the user, Jono & Johno will offer to have the item returned for repair at user expense. Our workshop rate is $60 per hour.

HOW DO I RETURN MY PRODUCT IF IT’S COVERED BY WARRANTY?

If you’re in reasonable driving distance of a Jono and Johno outlet, you can physically return the product yourself. Please contact us in advance to arrange a return authority.

If you are not within reasonable driving distance, Jono & Johno will provide you with a return authority and an address to return the product to. Where Jono & Johno is at fault, a postage-paid return label will be provided.

EXCEPTIONS TO THE RULE

If your product is out of warranty and is buggered, even though you’ve hardly used it, give us a call or shoot us an email. If there is a manufacturer fault or the item should have lasted a lot longer than it has, we’re happy to assess it outside of the warranty period. We do this on a case-by-case basis.

SKU	PBCS001
Model #	PBCS001
Barcode #	682157255382
Brand	Perla Barb
Shipping Weight	6.7500kg
Shipping Width	0.260m
Shipping Height	0.290m
Shipping Length	0.510m
Shipping Cubic	0.038454000m3
Unit Of Measure	ea
